36-inch wire mesh cable tray CF150-900EZ for electrical cable management and routing, heavy-duty steel wire basket design with raised sides, ideal for commercial and industrial installations.

Cable Tray - EZ Finish, 6H, 36W, 120L

CF150/900EZ Cablofil
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getAggregateRating, 18ms
  • REVIEWS, PRODUCT
  • bvseo-msg: The resource to the URL or file is currently unavailable.;

Our Wire Mesh Tray creates a dedicated pathway for all low-voltage and data cables. It is constructed of precision-engineered, high-quality welded steel wire and is the result of decades of research gained from the installation of over 160,000 miles of tray across the globe. Our tray features our Safe-T-Edge design that involves "T" welding the lateral wires to the bottom edge of the top wires and carries a patent for optimized wire diameters for maximized working load.
Height 6.0 in
Width 36.0 in
Where To Buy
  • Send
  • Save as PDF
  • Add to favorites Remove from favorites
Features

Features

  • Special Safe-T-Edge: protects installers from sharp ends while it prevents cables from fraying.
  • Trays are field-modifiable to almost any configuration while providing maximum strength at minimum weight
  • UL Classified to NEC requirements and follows NEMA-VE2 guidelines
  • Patented design for optimized wire size. Patent Number 6,138,961
Specifications

Specifications

General Info
Type Straight Sections
Material Steel
Finish Electrozinc
Application Sector Commercial, Data Center, Industrial
Product Line Cablofil
Country Of Origin United States
Bottom Type Wire Mesh
UPC Number 800388547452
Dimensions
Product Depth US 6.0 in
Product Height US 6.0 in
Product Length US 10.0 FT
Product Width US 36.0 in
Product Weight US 42.311 lb
Tray Height 6 in
Additional Information
Energy Savings No
RoHS Compliant Yes This product meets the material restrictions of Article 4 of the RoHS Directive (2011/65/EU), including Commission Delegated Directive 2015/863.
Resources
Reviews

Reviews

  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 5ms
  • REVIEWS, PRODUCT
  • bvseo-msg: The resource to the URL or file is currently unavailable.;
Questions & Answers

Questions & Answers

What steel mesh tray do I use in data centers?

Asked by: Richard cavaluzzi
Data centers typically use wire mesh tray with an EZ finish. The size of the mesh is determined by the type and quantity of cables to be installed. If you need direction in sizing cable tray, please use Cablofil's online tool, Submittal Builder, which includes a calculator, or contact Cablofil tech support at technical.support-CAB@legrand.us.
Answered by: Cablofil Tech Support
Date published: 2026-04-08
