Wiremold® 1200 Series™ Service Fittings are bellcap style pedestal fittings used in single service power and communication applications. The split bell cap design protects the electrical or communication cabling exiting the fitting from damage. Multiple fittings are required for two or more services. 1200 Series Service Fittings are designed to be threaded directly into a 2" IPS [51mm] preset or afterset insert to activate Walkerduct® Underfloor Duct. It can also be applied as an afterset on Walkercell® Cellular Raceway. 1200 Service Fittings are suitable for new and renovation construction and is available in aluminum and brass finishes. All power fittings are UL listed to U.S. safety standards.
- Send
- Save as PDF
-
FavoriteAdded to Favorites Go to favoritesRemove from favorites?Something went wrong. Please try again later.
Specifications
General Info
Product Line | Wiremold | ||
UPC Number | 786564222217 | ||
Country Of Origin | United States | ||
Construction | Not Assembled | ||
Application Sector | Commercial | ||
Standard | cULus Listed Underfloor Raceway Fittings: File E11912, Guide RQKX Meets Article 390 of NEC |
Additional Information
RoHS Conformant | Yes | This product meets the material restrictions of Article 4 of the RoHS Directive (2011/65/EU), including Commission Delegated Directive 2015/863. |
Buy American Act Compliance
NAFTA | Yes |
Technical Information
Cable Entry | Through Floor in |
