Plug-In Outlet Center Unit / Rack Mount 120V/15A/6 rear O/L /lighted switch/15' cord/Premium Grade Surge
R5S-15
Wiremold
Bazaarvoice SAP Hybris Integration Version 2.8.1
Six rear outlets, lighted switch, 15A. 15' (4.6m) cord. Sentrex high performance surge protection.
- Send
- Save as PDF
-
Added to Favorites Go to favoritesRemove from favorites?Something went wrong. Please try again later.
Specifications
General Info
Product Line | Wiremold | ||
UPC Number | 786776100822 | ||
Country Of Origin | Mexico | ||
Application Sector | Residential/Commercial | ||
Standard | cULus Recognized: File E66421: Guide XBYS2, XUHT2, VZCA11 | ||
Type | PIOC |
Dimensions
Product Width US | 19.0 in | ||
Product Height US | 2.57 in | ||
Product Length US | 1.75 in |
Buy American Act Compliance
NAFTA | Yes |
Technical Information
Phase | Three stage | ||
Frequency Rating | +50dB Hz | ||
Connection | Cord-ended | ||
Class | 75 | ||
Amperage | 15 A | ||
Short Circuit Rating | 56000 Amps [32000 Amps L-N 12000 Amps L-G 12000 Amps N-G] | ||
Response Time | <1 ns | ||
Mounting Type | Rack Mounting | ||
Mounting | Yes | ||
Type of Indicators | Light | ||
Voltage | 120.0 V |
Resources
Installation Instructions
Reviews
Bazaarvoice SAP Hybris Integration Version 2.8.1
Questions & Answers
What are the mounting hole locations? What are the overall dimensions?
Mounting hole locations measure 18.31" center to center and overall product length (including mounting ears is 19".
For complete dimensional information for this item please reference the attached drawing.
Date published: 2021-02-08
