Discontinued - Illuminated Decorator Switch, Brown

Single Pole, Back and Side Wire, Illuminated Decorator Switch, 20 amps, 120 volts, Brown. �

Color Brown

Send
Save as PDF
Added to Favorites Go to favorites

Remove from favorites?

Something went wrong. Please try again later.

Features

Impact-resistant polycarb back body and frame.
Cushioned thermoplastic paddle assures smooth, quiet, long term operation.
Unique single rocking butterfly contact provides long term consistent performance with significantly fewer moving parts.
Internal screw-pressure-plate back and side wire capability for easy installation with #14 - #10 stranded or solid copper/copper clad wire.
Terminals made of high conductivity brass and serrated for maximum wire gripping.
Silver alloy contacts integrally formed to the butterfly actuator assures reliable performance.
Integral auto-ground clip for positive ground to metal boxes.
Tri-drive ground, terminal, and mounting screws.
All terminal screws backed out, ready-to-install.
For covering patents, see www.legrand.us/patents.

General Info

Color	Brown
Type	Decorator, Switch
Finish	Matte
Application Sector	Commercial, Residential
Product Line	Pass & Seymour
Country Of Origin	Mexico
Features	Decorator Style, Illuminated
Wall Plate Included	No
Number of Switches	1
Switch Type	Paddle
Warranty Type	1-Year Limited Warranty
Standard	UL 20
UPC Number	785007243079

Listing Agencies / 3rd Party Agencies

CSA Listed	Yes
cULus Listed	Yes

Technical Information

Amperage	20 A
Connection Location	Back and Side
Requires Neutral Wire	No
Wire Connection Type	Screw Terminals
Indoor/Outdoor	Indoor
Load Rating	20 A @ 120 VAC
Load Type	CFL, Fluorescent, Halogen, Incandescent, LED, Universal, Xenon
Mounting Type	Wall Box
Number of Gangs	1
Number of Poles	Single Pole
Operating Temperature	-20°-60°C, -4°-140°F
Operating Temperature Max	140 °F
Operating Temperature Min	-4 °F
Horsepower Rating	1 HP @ 120 VAC, 2 HP @ 240 VAC
Throw Type	Single Throw
Terminal Accommodation	#14 AWG - #10 AWG
Voltage	120 VAC

Resources

Legrand aluminated light switch doesn’t aluminate,  Why.  The switch functions as it should concerning turning on and off the light.  I tried two different switches with the same results!

Asked by: Anonymous

I'd recommend you call in to Technical Support so we can offer guidance on how the device should be properly wired. You can reach us at 844-957-3783.

Answered by: Wiremold Tech Support

Date published: 2023-01-04

Asked by: Tom Kobe

This switch is illuminated with an Amber color neon bulb.

Answered by: Legrand Technical Support

Date published: 2021-09-27

Asked by: Alan

Illuminated when OFF switches are designed for Incandescent bulbs and may cause CFL/LED's to flicker.

Answered by: Legrand Technical Support

Date published: 2019-09-18
