How to Install an Outlet in a Kitchen Island

July 31, 2026

Looking for ways to elevate your kitchen design with a blend of modern aesthetics and code-compliant functionality? The Legrand Kitchen Countertop Outlet provides a sleek, water-resistant power solution specifically engineered for kitchen islands and peninsulas. Installing this outlet in a kitchen island is quick, simple and requires only a few tools to get the job done.

Why Choose a Countertop Outlet?

This outlet is a code-compliant, UL 498-certified solution that meets National Electrical Code (NEC) 406.5(E) requirements for countertop applications. As outlets along the side of kitchen islands and peninsulas are no longer permitted in accordance with 2023 NEC updates, an alternative solution is required for delivering power to these high-traffic spaces.

Key Features of the Countertop Outlet Include:

Spill Protection

Successfully passed a half-gallon liquid spill test to ensure maximum safety in busy kitchens.

Durable Design

Built with corrosion and chemical resistance to withstand daily wear and tea

Versatile Finishes

Available in two finishes and pairs with four cast metal options to match existing hardware and décor.

Installing a Kitchen Outlet in an Island or Peninsula

The device features a compact design with a "Tail and Body" snap-fit system that eliminates the need for a standard junction box. With just a few tools, the installation of the Kitchen Countertop Outlet is estimated to take about 15 minutes. Follow the steps below, watch the installation video and download the installation instructions for a comprehensive overview of how to install an outlet in a kitchen island.

Gather all Required Tools

Outlet and tail that come together
Lid (if using)
GFCI protected circuit
Suitable conduit for the installation
Armored cable stripper
Wire stripper
Anti-short bushings (5/16” female grommet)
Suitable ½" cable connector
2 ¼ hole saw

Step 1. Prepare the Countertop

Start by double-checking that the countertop thickness is between 0.50" and 1.6"

Determine if you are installing the device with or without the optional decorative lid.

For installations with a lid, you will need a 2-1/4" hole saw.
For installations without the lid, a 2"-hole saw is used.

Step 2. Wire the Tail

Safety is paramount: always turn off power at the service panel before beginning.
Strip the cable sheathing to expose 3.5 inches of insulated conductors.
Connect the wires to the proper terminals: (Green for Ground, White for Neutral, Black/Red for Hot)
Torque the terminal screws to 14-16 inch-pounds for a secure connection

Step 3. Final Assembly

Once the wiring is complete and the tail cover is replaced, insert the outlet body into the hole.
Hand-tighten the nut from underneath the counter, then use pliers to turn the nut a final 1/2 turn to secure it.
Align the post and insert the tail into the body until you hear a "CLICK", indicating the snap feature has engaged

Note: For safety and compliance, it is highly recommended that these wiring devices be installed by an electrician or other qualified person.

Whether you are remodeling or building fresh, the Kitchen Countertop Outlet offers the perfect combination of safety and style for the heart of your home.
