Specifications: Single Pole, Compatible with all loads, 600W 120V 60Hz Rating

radiant® Single-Pole 3-Way Vacancy Sensor, Tri-Color

Name: radiant® Single-Pole 3-Way Vacancy Sensor, Tri-Color
Brand: radiant Collection
SKU: RRW600VTC
Availability: InStock

RRW600VTC radiant Collection

$41.15 USD

Never worry about leaving the lights on, with the radiant Registered Vacancy Sensor. It automatically shuts off when a room is empty, and includes an adjustable delay setting of up to 20 minutes to match your needs. Designed for ease and style, it features a built-in locator light, and the sleek, clean lines of radiant Registered for a sophisticated touch. Made exclusively for use with screwless Wall Plates from the radiant Registered Collection, sold separately.

Color Tri Color (White, Ivory, Light Almond)

Free shipping on orders over $49 & free returns

Quantity

In Stock

Send
Save as PDF
Added to Favorites Go to favorites

Remove from favorites?

Something went wrong. Please try again later.

Features

Passive infrared (PIR) sensor switch technology with 180° coverage up to 600 sq. ft. Rated for up to 600W (5A) of LED lighting.
Works with virtually any bulb/fixture, including: LED, incandescent, fluorescent, compact fluorescent (CFL), magnetic low-voltage (MLV) and electronic low-voltage (ELV), 1/6 hp.
Turn the light on when you enter, and let it turn itself off automatically after you leave for true convenience. Perfect for bathrooms, hallways, closets, garages, and more.
Locator light illuminates when switch is off, emitting a soft glow to help you find it in the dark.
Features an adjustable time delay to off after no motion is detected. Delay settings range from 30 seconds to 20 minutes after the room is vacated (default 20 minute delay).
Manual ON/Auto OFF functionality. Meets California Title 24 requirements for automatic off lighting control.
Replace any basic light or fan switch in 15 minutes or less. Supports single pole and multi-location installs. No neutral required.
Complete the look with a sleek, screwless radiant® Wall Plate, and coordinate with other designer switches and outlets available from the radiant® Collection.
More color options available to fit any style, including finishes to match current hardware and lighting trends.

Specifications

General Info

Color	Ivory, Light Almond, White
Finish	Matte
Application Sector	Hospitality, Light Commercial, Multi-Dwelling Unit, Residential
Product Line	Pass & Seymour
Country Of Origin	China
Features	Adjustable Time Delay, Motion Sensor
Installation Location	Wall Box
Switch Type	Motion Sensor, sofTap
Warranty Type	Limited Lifetime Warranty
Standard	cULus
UPC Number	785007496604

Dimensions

Product Depth US	1.88 in
Product Height US	2.63 in
Product Width US	1.69 in

Listing Agencies / 3rd Party Agencies

cULus Listed

Yes

Technical Information

On Function	Manual On
Requires Neutral Wire	No
Wire Connection Type	Flying Leads
Environmental Conditions	Indoor Use Only
Indoor/Outdoor	Indoor
Input Voltage	120 VAC
Line Frequency	60 Hz
Load Rating	120V 5A (ELV), 120V 5A 600W (CFL), 120V 5A 600W (LED), 120V 600VA (Fluorescent), 120V 600VA (MLV), 120V 600W (Halogen), 120V 600W (Incandescent)
Load Type	CFL, Fan Motor, Halogen, Incandescent:Fluorescent, LED
Location Rating	Dry
Mounting Type	Wall Box
Number of Poles	Multi-Location, Single Pole 3 Way
Timer Duration	20 Minutes, 30 Seconds-20 Minutes
Operating Humidity	0-95% RH (Non-Condensing)
Horsepower Rating	1/6 HP @ 120 VAC
Response Frequency	60 Hz
Sensing Range	Major Motion 35 ft, Minor Motion 20 ft
Sensitivity	60Hz
Sensor Type	Vacancy
Sensor Technology	Passive Infrared (PIR)
Sensor Coverage	600 sq ft
Sensor Coverage Pattern	180 °
Target Size	180 deg
Voltage	120 VAC
Wattage	600 W
Wire Size	#14 - #10 AWG

Resources

Can I use this switch if the wire that runs to the light/load is in the box with the mechanical 3-way switch?  How would I wire this?  Thanks.

Asked by: Steve22

Thank you for your inquiry. We require additional information to assist you further with your request. Please contact Legrand Pass & Seymour Technical Support at (800) 223-4185 between 8:00 a.m. and 6:00 p.m. EST or via email at Tech.Support@legrand.us.

Answered by: Pass & Seymour Technical Support

Date published: 2024-07-01

Is it ok to use this switch with a ceiling fan light?

Asked by: Daniel Alejo

Thank you for your inquiry. The RRW600VTC supports the following loads: LED/CFL: 600W (5A) Incandescent/ELV: 600W MLV: 600VA ELV: 5A Motor: 1/6 hp Best Regards, Technical Support

Answered by: Pass & Seymour Technical Support

Date published: 2024-04-11

is this switch Ok on a 20 amp circuit?

Asked by: merlin Huff

Yes this device can be used on a 20 A, 120V circuit.

Answered by: Wiremold Tech Support

Date published: 2023-04-10

We just bought new construction that is full of these discontinued switches with no instructions. How do you change the settings?

Asked by: Laura

The Radiant Vacancy sensor is still an active model number. Here is the link to the full set of instructions for it. See Table 1 and Table 2 for changing it's settings. https://legrand.webdamdb.com/directdownload.php?ti=55653156&tok=6WqaBwyH0xLnEKUBoQO49gRR
