Q-Series 4 Panel Standard Density Wall Mount Fiber Enclosure Black

WQS-04P Ortronics
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getAggregateRating, 12ms
  • REVIEWS, PRODUCT
  • bvseo-msg: The resource to the URL or file is currently unavailable.;

The Q-Series Wall Mounted fiber enclosure system is designed to support standard density LAN or POL applications in building networks. The all steel chassis enables reliable protection and management of fiber optic cable patching, splicing, and connecting. The enclosure also enables distribution of backbone cabling to active equipment, switching, or cross/interconnect horizontal area. The 1 panel footprint accommodates up to 24 LC fibers, the 2 panel accommodates up to 48 LC fibers, while the 4 panel accommodates up to 96 LC fibers. Each enclosure is compatible with OFP Adapter Panels, Compact 12 Fiber Splice Trays, and LM2 Pre-terminated or M2 Splice Cassettes.

Number of Panels 4

Features

  • Standard Density: Accepts 12 or 24 fiber LM2 pre-terminated or M2 splice cassettes, FST4-F012 splice tray (WQS-02P & WQS-04P only)
  • Low-Profile Design: Providing unobtrusive protection and management of all enclosed cabling infrastructure
  • Cable Ingress and Egress: Four ingress or egress points with rubber grommets help to protect and route all connectivity infrastructure.
  • Cable Management: Protect and safely route all sensitive fibers with the included cable management system, central strength member bracket, and bend limiters
  • Low-Profile Design: Providing unobtrusive protection and management of all enclosed cabling infrastructure
  • Cable Management: Protect and safely route all sensitive fibers with the included cable management system, central strength member bracket, and bend limiters

Specifications

General Info
Product Line Ortronics
UPC Number 662875029199
Country Of Origin China
Included Rubber grommets, labels, cable management clips, cable cradle
Type Enclosure
Technical Information
Compatibility OFP/M2/LM2
Frame Steel
Mounting Wall

Reviews

  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 2ms
  • REVIEWS, PRODUCT
  • bvseo-msg: The resource to the URL or file is currently unavailable.;

Questions & Answers

How does a conduit connect to the Q-series enclosure? Does the removal of the rubber grommet allow conduit to extend through the grommet opening? If so, can threaded conduit be used and then attached using a plastic locknut? Installation videos?

Asked by: AdeO
