radiant® 2-Wire Fluorescent Dimmer, Tri-Color

Name: radiant® 2-Wire Fluorescent Dimmer, Tri-Color
Brand: radiant Collection
SKU: RHFB83PTC
Availability: OutOfStock

RHFB83PTC radiant Collection

$55.82 USD

Upgrade your space with precise dimming and exceptional style. This dimmer is designed for use with 2-wire fluorescent fixtures, and features the clean lines and smooth control of the radiant® Collection. Made exclusively for use with screwless Wall Plates from the radiant® Collection, sold separately.

Color Tri Color (White, Ivory, Light Almond)

Out of Stock on Legrand.us

Send
Save as PDF
Added to Favorites Go to favorites

Remove from favorites?

Something went wrong. Please try again later.

Features

Replaces any basic switch or dimmer with ease, in both single-pole and 3-way applications. For use with 2-wire fluorescent lighting fixtures.
Low-profile paddle switch offers smoother On/Off control, while a separate, ergonomic slider allows you to adjust light levels with precision.
Locator light illuminates when switch is off, emitting a soft glow to help you find it in the dark.
Constant memory features returns lights to their previous level after a power failure or outage.
No derating* required for 2-gang applications. *Reducing the maximum wattage a dimmer can handle. This is sometimes required for multi-gang applications.
Features durable, high-impact resistant thermoplastic construction.
More color options available to fit any style, including finishes to match current hardware and lighting trends.
Complete the look with a sleek, screwless radiant® Wall Plate, and coordinate with other designer switches and outlets available from the radiant® Collection.

Specifications

General Info

Color	Ivory, Light Almond, White
Type	Dimmer
Finish	Matte
Application Sector	Commercial, Hospitality, Residential
Product Line	Pass & Seymour
Country Of Origin	China
Features	Color Change Kit, Locator Light, Low-End Trim (Dim Range)
Number of Switches	1
Switch Type	Paddle, Slider
Warranty Type	Limited Lifetime Warranty
Standard	CSA Listed, cULus, UL Listed
UPC Number	785007053432

Dimensions

Product Depth US	1.25 in
Product Height US	4.25 in
Product Width US	2.5 in

Listing Agencies / 3rd Party Agencies

cULus Listed

Yes

Technical Information

Requires Neutral Wire	No
Wire Connection Type	Screw Terminals
Dimming Compatibility	Forward Phase
Environmental Conditions	Humidity: Less than 95% non condensing
Frequency Rating	60 Hz
Indoor/Outdoor	Indoor
Load Rating	120V 8A (Fluorescent)
Load Type	Fluorescent
Mounting Type	Wall Box
Number of Poles	Single Pole 3-Way
Maximum Humidity	90% (relative humidity, non-condensing)
Preset	Yes
Voltage	120 VAC
Wire Size	#14 - #10 AWG
